WP18L.WP25L.WP32L船用压缩机气阀系列添加时间：2021-06-24 编辑：上海苏宁空压机有限公司
    点击图片查看原图 |
|
产品详情
|
型号
|
排气压力(MPa)
|
级数
|
转速(50Hz)
|
转速
(60Hz) |
容积流量(m3/h)
|
轴功率
(kW) |
电机功率(kW)
|
冷却空气需要量（L/min）
|
外形尺寸
(mm) |
|
WP18L
|
3.0
|
2
|
970
|
|
12
|
2.8
|
3
|
12
|
884×640×534
|
|
|
1150
|
14.3
|
3.2
|
4
|
14
|
||||
|
1450
|
|
18
|
3.8
|
5.5
|
18
|
||||
|
|
1750
|
22
|
4.8
|
5.5
|
22
|
||||
|
WP25L
|
3.0
|
2
|
970
|
|
16.5
|
3.6
|
4
|
17
|
884×640×534
|
|
|
1150
|
20
|
4.2
|
5.5
|
19
|
||||
|
1450
|
|
24.5
|
5.4
|
7.5
|
25
|
||||
|
|
1750
|
30.5
|
6.4
|
7.5
|
30
|
||||
|
WP32L
|
3.0
|
2
|
970
|
|
20.6
|
4.7
|
5.5
|
21
|
930×640×534
|
|
|
1150
|
25
|
5.6
|
7.5
|
25
|
||||
|
1450
|
|
31.5
|
6.8
|
7.5
|
31
|
||||
|
|
1750
|
38
|
8.2
|
11
|
39
|
||||
|
WP80L
|
3.0
|
3
|
|
870
|
44
|
9
|
11
|
42
|
1326×780×830
|
|
970
|
|
50
|
10
|
15
|
46
|
||||
|
|
1170
|
64
|
13
|
15
|
60
|
||||
|
1470
|
|
80
|
15
|
18.5
|
69
|
||||
|
|
1770
|
92
|
18
|
18.5
|
83
|
||||
|
WP100L
|
3.0
|
3
|
|
870
|
59
|
12
|
15
|
53
|
1422×880×1086
|
|
970
|
|
66
|
13.5
|
15
|
59
|
|
|||
|
|
1170
|
78
|
16
|
18.5
|
74
|
|
|||
|
1470
|
|
99
|
20
|
22
|
88
|
|
|||
|
|
1770
|
118
|
24
|
30
|
106
|
|
|||
|
WP120L
|
3.0
|
3
|
|
870
|
72
|
14.5
|
15
|
70
|
1422×880×1086
|
|
970
|
|
81
|
16
|
18.5
|
78
|
|
|||
|
|
1170
|
98
|
19
|
22
|
88
|
|
|||
|
1470
|
|
121
|
24
|
30
|
116
|
|
|||
|
|
1770
|
145
|
30
|
37
|
143
|
|
|||
|
WP150L
|
3.0
|
3
|
|
870
|
90
|
18
|
18.5
|
89
|
1422×880×1086
|
|
970
|
|
100
|
20
|
22
|
99
|
|
|||
|
|
1170
|
117
|
23
|
30
|
111
|
|
|||
|
1470
|
|
150
|
30
|
37
|
148
|
|
|||
|
|
1770
|
180
|
38
|
45
|
176
|
|
|||
|
WP250L
|
3.0
|
3
|
|
870
|
135
|
26.5
|
30
|
130
|
1590×930×1117
|
|
970
|
|
150
|
29.5
|
30
|
145
|
|
|||
|
|
1170
|
180
|
37
|
45
|
180
|
|
|||
|
1470
|
|
225
|
44
|
45
|
217
|
|
|||
|
|
1770
|
175
|
53
|
55
|
264
|
|
|||
|
WP300L
|
3.0
|
3
|
|
870
|
180
|
33.6
|
37
|
155
|
2116×926×1026
|
|
970
|
|
200
|
37.5
|
45
|
173
|
|
|||
|
|
1170
|
240
|
44
|
45
|
203
|
|
|||
|
1470
|
|
300
|
54
|
55
|
259
|
|
|||
|
|
1770
|
350
|
69
|
75
|
319
|
|
|||
|
WP18L
|
0.8/1.0
|
1
|
|
1170
|
20
|
2.1
|
3
|
11
|
884×640×534
|
|
1
|
1450
|
|
24
|
2,.5
|
3
|
14
|
|||
|
1
|
|
1750
|
30
|
3.2
|
4
|
18
|
|||
|
WP25L
|
0.8/1.0
|
1
|
|
1170
|
38
|
3.6
|
4
|
20
|
884×640×534
|
|
1
|
1450
|
|
44
|
4.2
|
5.5
|
24
|
|||
|
1
|
|
1750
|
55
|
4.2
|
5.5
|
36
|
|||
|
WP32L
|
0.8/1.0
|
1
|
970
|
|
38
|
5.4
|
5.5
|
30
|
930×640×534
|
|
1
|
|
1170
|
45
|
5.6
|
7.5
|
46
|
|||
|
1
|
1450
|
|
56
|
6.8
|
7.5
|
56
|
|||
|
1
|
|
1750
|
68
|
8.2
|
11
|
68
|
